Enclosure: Weather Proof IP 67 / NEMA 4X4 X
Cable Entries: Two NPT 1/2"
Ambient Temperature: -20°C to 80°C
Terminal Strips: 8 points (0.08-2.5m)
Position Indicator: 0 ~ 90 (90 turn free join) , Close : Red, Open : Yellow
Switches: Mechanical Switch X 2 , Proxmity Sensor X 2
Painting: Chrome Polyester powder coating (Black)
Enclosure: Weather Proof IP 68
Cable Entries: Two PF 1/2 PT 1/2 M20, PG13.5
Position Indicator: Three position L port / T port , Close : Red, Open : Green
Painting: Nylon others on request Red, green, blue, yellow, silver
Reach out for tailored solutions. Our team is ready to assist. Submit an inquiry and experience excellence in valve automation solutions.
